KMG-20 Multi-Functional Gauge

The KMG 20 Marine Gauge is a Multi-Functional Digital instrument developed specifically for boats, yachts, and marine applications.

The instrument integrates major displaying functions and it offers 10 different display settings for customers.

View Distribution List


Share
Description

Product Dimension: 2″, 52mm

Mounting Dimension: 52 mm

Protection Rating: IP67

Resolution: 320 x 320 Pixels

Input Signal: NMEA 2000, J1939, and Support 2 Analog signals input: (Resistance and Speed)

Operating Voltage: 9-32V D

Operating Current: <80mA (12V)

Operation Temperature: -4°F~158°F

Storage Temperature: -22°F~176°F

Operation Settings: Mobile Phone App (Bluetooth)

Background Brightness: 10-100%

Package Content: 1.5m Cores CAN Cable, 1m 6 Cores Analog Cable, Instructional Manual



Product Data Sheet
KMG-20 Multifunctional Gauge Spec Sheet
Dimensions 7 × 5 × 5 in
Bezel

Black Plastic, Stainless Steel, White Plastic

Face Plate

Black, White
